Metallurgy Collaboration - Melting Secton

Melting Secton

Induction Furance – of 550 KW - 500 Kgs with melt rate of 1 MT per hour – Make Inductotherm

Pouring And Mould Handling

Fully mechanised mould handling system with mono-rail pouring system

Pouring And Mould Handing - Metallurgy Collaboration

1
2
3
4

Mould and Core Section

Shell core shooter (15 Nos ) - with Horizontal and Vertical parting – with top and bottom blow - Make – Susha & Span

Shot Blasting & Fettling

Shot Blasting Machine – ( 2 Nos ) –300 kgs per 5 minuted–Conveyor Belt Type - Twin Turbine - Make Surfex
Grinder , Chippers , Pneumatic grinder .
Sand Blasting – for cleaning of casting internal cavity

1
2

1
2

Laboratory Testing

SChemical Analysis – Spectrometer –Make - MetalPower - 16 elements
Micro Structure – Micro scope with image analyzer – Make Metalsoft
Hardness Tester – BHN - PC based – Make FIE
Shell Sand Testing Equipments - H.T.S Machine , Gas Evolution , Peel Back Tester , Sieve Analyzer

Machining facility

1
2

Horizontal Machining Centres
Vertical Machining Centres
Drill Tap Centres
CNC Turning Centres
Milling Machines
Drilling Machines
Broaching Machines
Leak Testing
Washing

Inspection facility

Coordinate Measuring Machine
Height Master
Surface Tester
Hardness Tester
Millipore Value Tester

1
2

DISA HPML line with auto pouring System

DISA HPML line with auto pouring System
